Breather Valve
KSPR/PS TYPE
The model KSPR and KSPS pressure vacuum valves are an advanced design for vent to atmosphere applications. Designed manufactured and tested according to the API 2000 code. Utilize the latest technologies to provide protection against positive or vacuum over pressure and prevent air intake, evaporative losses of product and help to contain odorous and potentially explosive vapours.
The KSPR is a weighted pallet model, designed to handle over pressure with a minimum pressure of 20mmW.C and a maximum setting of 700mmW.C
The KSPS is a spring loaded model, designed to handle over pressure with a minimum pressure of 700mmW.C and a maximum setting of 9,000mmW.C.
Body materials are available in Aluminium, Carbon Steel, 304SS and 316SS with various trims to suit individual requirements.
Sizes range from 50mm through to 350mm with ANSI 150lb flanges as standard.
(Different connections available on request).
